Benefits
- Powerful & complete drive unit.
- Heavy-duty single-chain.
- Versatile, they can transport feed, silage and grain.
- Wide range of accessories for optimum customization, whatever the complexity of the installations.
- Loading hopper
- Motor pulley
- 9'' model: galvanized steel
- 11 ½'' model: galvanized or stainless steel
- Discharge funnel Optional
- 5' (152 cm) or 10' (305 cm) snap-on cover Optional
- Adjustable decline section from 0° to 40° Optional
- Galvanized steel diverter (11 ½'' model) Optional
Available on wheels for mobile use
The 16" (41 cm) wheel kit makes it easy to move the single-chain conveyors. This option is available for conveyors up to 15' (4.6 m).
| 9'' Model | 11 1/2'' Model | |||||
| Length of conveyor | Up to 20' (6.1 m) | 20' to 35' (6.1 m to 10.7 m) | 35' to 50' (10.7 m to 15.2 m) | Up to 35' (10.7 m) | 35' to 70' (10.7 m to 21.3 m) | 70' to 100' (21.3 m to 30.5 m) |
| HP recommended | 1 HP | 1 1/2 HP | 2 HP | 1/2 HP | 2 HP | 3 HP |
Specifications
| 9'' Model | 11 1/2'' Model | |
| Chain speed (approx.) | 124 ft/min (38 m/min) | 140 ft/model (43 m/min) |
| Operating capacity (approx.) | 66 ft3/min (1.9 m3/min) | 96 ft3/min (2.7 m3/min) |
| Maximum length | 50 ft (15 m) |
150 ft (46 m) or 70 ft (21 m) for reversible conveyor |
| Chain model | 662 chain | 667-H chain or heavy duty 667X chain and UHMW paddles |
| Drive unit | Direct drive with 70 series gearbox | Direct drive with 70 or 80 series gearbox |
| Frame sections |
Galvanized steel: 2 1/2' (76 cm), 5' (152 cm), 8' (244 cm), 10' (305 cm) |
Galvanized steel or stainless steel: 2 1/2' (76 cm), 4' (122 cm), 5' (152 cm), 8' (244 cm), 10' (305 cm) |
